Posiflex HS-2510
POSMarket SKU: Z1825
This model is available in 5 different configurations. Select a configuration below or contact our experts on 1300 737 998.
The HS-2500 Series is the solution for the counter space problem. It takes the all-in-One concept to the extreme! The compact all-in-one design of HS-2500 Series frees more room for counter space, so that the store owner can display and promote more merchandise to maximize sales opportunities.
Product Overview
The Posiflex HS-2500 Series is the solution for the counter space problem. It takes the all-in-One concept to the extreme! The compact all-in-one design of HS-2500 Series frees more room for counter space, so that the store owner can display and promote more merchandise to maximize sales opportunities.
Features
- Fan free POS Terminal
- All-in-one design
- 9.7'' LCD PCAP Touch Screen
- Intel J1900 Quad Core CPU up to 2.42 GHz 2M Cache and DDR3L memory
- Small footprint
- Either build in 80mm Printer or Presentation scanner
- Optional build in RFID Reader, MSR, Contact Card Reader, Fingerprint module
- Several Customer Display Options available
- Comes with Bracket to lock down to bench for better stability
Product Specifications
| SYSTEM | |
| CPU | Intel Bay Trail Qual Core up to 2.42G, 2M cache |
| Memory | DDR3L 1333 MHz, SO-DIMM socket x 1, max 8 GB, default 2 GB |
| Storage device(s) | In Australia standard with 32 GB SSD Also Available with HDD or larger SSD on request |
| TOUCH & DISPLAY | |
| Display | 9.7' LCD Display |
| Resolution | 1024 x 768 |
| Tilt Angle | 17 ~ 45 |
| Touch Panel | True-Flat PCAP touch with 10 point multi-touch support |
| I/O | |
| I/O Ports | 3 x RS-232 interfaces; DB9 x2 & RJ-45 x1 with 5V or 12V support on COM1/COM2/COM3 4 x USB Ports: 1 x USB3.0/2.0 & 3 x USB2.0 1 x Parallel Port 1 x VGA Port for 2nd Display with 12V power for Posiflex Monitor 1 x Cash Drawer Port (Controls 2 drawers with optional Y-cable) 1 x 10/100/1000 Ethernet Port 1 x Mini-PCIe Slot |
| I/O Devices (Intergrated) | 80 mm Thermal Printer, 200 mm/sec, with Auto Cutter or Laser Omni Directional Presentation Scanner Optional: MSR 3 tracks ISO or JISII HID/VCOM Selectable Smartcard Reader RFID Reader HID/VCOM Selectable Fingerprint Reader Mini-PCIe Wifi Module |
| Audio | Line out Only |
| OS Support | POSReady 7 / Windows 7 / Windows Embedded 8.1 Industry / WIN 10 IoT / Linux per request |
| ENVIRONMENTAL | |
| Environmental Sealing | IP65 to front of screen |
| Operating Environment | SSD: 0 C ~ 50 C 20% ~ 90% Relative Humidity HDD: 0 C ~ 40 C 20% ~ 90% Relative Humidity |
| Storage Environment | -20 C ~ 70 C, 10% ~ 90% Relative Humidity |
| Power Supply | External Power Adapter 12V, 100W |
| PHYSICAL | |
| External Dimensions (WxDxH) | 224.5mm x 185mm x 387mm |
| Weight | 4.2 Kg |
