SAM4S SAP-6600
POSMarket SKU: Z13987
SAP-6600/WGOD12SNB: SAP-6600 POS Terminal. 15" PCAPS Touch System, Intel Celeron N3160 Quad Core, 2 GB DDRIII, 16 GB M.2 SSD, WiFi & BlueTooth, Android 6.0
Robust and fanless, 15" PCAP Touch Screen POS Terminal for Android POS applications with Wifi and Bluetooth.
Product Overview
Features
- Android 6.0 POS Touch Terminal
- Low energy consumption
- High resolution 15" LED LCD
- LCD Resolution 1024 x 768 (XGA)
- Powerful performance with INTEL N3160 Quad core CPU
- Silent Fan Free system for high reliability
- 16 GB Mass Storage Capacity
- Tool-less access for easy maintenance
- Multiple Interfaces for a full range of optional peripherals
- Optional 2 Line Customer Display or 7" Customer LCD Display, 3 Track MSR
Product Specifications
| SAP-6600 touch terminal | |
| CPU | Intel Celeron N3160 Quad core up to 2.24 GHz |
| Memory | DDRIII One slot. 2GB standard expandable to 8GB DDRIII |
| Storage device(s) | 16 GB SSD Standard in Australia & New Zealand |
| Display | 15" LED Backlight LCD Display |
| Resolution | 1024 x 768 |
| Touch Panel | True Flat PCAP Touch (Standard in Australia & New Zealand) Optional; 5 Wire Resistive touch (Special Order, MOQ Applies) USB I/F |
| I/O Ports | 3 x RS-232 Ports (2 x DB9, 1 x RJ45) with 5V/12V BIOS selectable
6 x Standard USB Ports (4 x USB 3.0 on Bottom, 2 x USB 2.0 on the side) 1 x 10/100/1000Mb Ethernet Port. Half/Full duplex capability 1 x VGA Port for 2nd Display + 12V power outlet 1 x Parallel port (Factory Option) 1 x Cash Drawer Port (Controls 2 drawers with optional Y-cable) 12/24V selectable 3 x Audio Ports (Line in & Line out/ Mic in) Wifi & Bluetooth Built-in (Standard in Australia & New Zealand) |
| OS Support | Android 6.0 (Marshmallow) |
| Environmental Sealing | IP55 to Front |
| Operating Environment | 0 ~ +40 °C, 20 ~ 85% RH with SSD |
| Storage Environment | -20 ~ +60 °C, 10 ~ 85% RH |
| Power Supply | DC 12V/5A |
| External Dimensions (WxDxH) | 380mm x 380mm x 380mm |
| Weight | 5.9kg |
