Hikvision DS-2CD2T66G2-2I/ 4I
POSMarket SKU: Z14320
This model is available in 6 different configurations. Select a configuration below or contact our experts on 1300 737 998.
6MP Outdoor AcuSense Gen 2 Bullet Camera
Product Overview
The most paramount feature with the AcuSense gen 2 cameras is the analytic alert which will generate alarm events that are searchable when reviewing recorded footage for specific incidents. This saves many man hours of wasted time reviewing irrelevant video trying to identify an event, saving the end customer time and money.
Features
- High quality imaging with 6 MP resolution
- Excellent low-light performance with powered-by-DarkFighter technology
- Efficient H.265+ compression technology
- Clear imaging against strong back light due to 120 dB true WDR technology
- Focus on human and vehicle targets classification based on deep learning
- Water and dust resistant (IP67)
Product Specifications
| Camera | |
| Image Sensor | 1/2.4" Progressive Scan CMOS |
| Min. Illumination Color: | 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Slow Shutter | Yes |
| Wide Dynamic Range | 120 dB |
| P/N | P/N |
| Day & Night | IR cut filter |
| Angle Adjustment Pan: | 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Lens | |
| Lens Type | Fixed focal lens, 2.8, 4, and 6 mm optional |
| Focal Length & FOV | |
| 2.8 mm | horizontal FOV 105.1°, vertical FOV 53.4°, diagonal FOV 128.6° |
| 4 mm | horizontal FOV 83.9°, vertical FOV 44.5°, diagonal FOV 100.8° |
| 6 mm | horizontal FOV 47.5°, vertical FOV 26°, diagonal FOV 54.5° |
| Iris Type | Fixed |
| Aperture | F1.6 |
| Lens Mount | M12 |
| DORI | |
| 2.8 mm: | D: 78.6 m, O: 31.2 m, R: 15.7 m, I: 7.9 m |
| 4 mm: | D: 95.6 m, O: 37.9 m, R: 19.1 m, I: 9.6 m |
| 6 mm: | D: 160.0 m, O: 63.5 m, R: 32.0 m, I: 16.0 m |
| Illuminator | |
| Supplement Light Type | IR |
| Smart Supplement Light | Yes |
| IR Range | |
| -2I: | up to 60 m |
| -4I: | up to 80 m |
| IR Wavelength | 850 nm |
| Video Compression | |
| Main stream: | H.265/H.264/H.264+/H.265+ |
| Sub-stream: | H.265/H.264/MJPEG |
| Third stream: | H.265/H.264 *Third stream is supported under certain settings. |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| H.264+ | Main stream supports |
| H.265+ | Main stream supports |
| Bit Rate Control | CBR/VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Image | |
| Image Parameters Switch | Yes |
| SNR | ≥ 52 dB |
| Target Cropping | Yes |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser Event |
| Basic Event | Motion detection (human and vehicle targets classification), video tampering alarm, exception |
| Smart Event | Scene change detection |
| Deep Learning Function | |
| Face Capture | Yes |
| Perimeter Protection | Line crossing detection, intrusion detection, region entrance detection, region exiting detection Supports human and vehicle targets classification General |
| Power Supply | 12 VDC +/- 25%, reverse polarity protection PoE: 802.3af, Class 3 |
| Power Consumption and Current | |
| -2I: | 12 VDC, 0.63 A, max. 7.5 W PoE (802.3af, 36 V to 57 V), 0.25 A to 0.16 A, max. 9W |
| -4I: | 12 VDC, 0.88 A, max. 10.5 W PoE (802.3af, 36 V to 57 V), 0.34 A to 0.21 A, max. 12 W |
| Approval | Protection IP67 (IEC 60529-2013) |
