Opticon OPN-3102
POSMarket SKU: Z14216
14904: OPN-3102 2D Bluetooth Data Collector with MFI Black
A 2D companion scanner in a compact design. It is lightweight and fits easily in your pocket, making it the ideal companion scanner to bring along. It has real-time data transfer through Bluetooth and, when no connection is available, can store data locally as well.
Product Overview
Applications
The OPN-3102i enables organizations to easily integrate barcode scanning in their business process or service to optimize efficiency. The simplicity of this scanner enables people to use it with only a short introduction, an easy way to start optimizing with. Some of the uses include field sales and service, retail point-of-sale, inventory management, asset tracking and visitor registration.
Features OPN-3102i
A few highlights why the OPN-3102i is the perfect companion to scan with:
- 1D & 2D scanning
- Apple MFi certified
- Bluetooth connection
- Lightweight
- NFC tag for easy Bluetooth pairing
- Wireless charging
- Up to 100 fps
The OPN-3102i is a powerful 2D scanner equipped with a high capacity battery so the scanner can go for hours without charging. The Bluetooth connection facilitates real-time data transfer to your system and is able to connect with any device including Apple. This means that any data shared with an Apple product is transferred more quickly. This companion scanner is also resistant to drops up to 1.5 meters without the need for special protection. The OPN-3102i comes in black and white, and the dedicated CRD-3000 cradle charges your device wirelessly. The OPN-3102i looks sleek, modern, and scans up to 100 fps.
Using the OPN-3102i is simple and straightforward. One button to scan the barcode and one button to correct any mistakes made, both actions providing visual feedback for smooth interaction.
Product Specifications
| Manufacturer | OPTICON |
| Product Family/Series | OPN3002 |
| OPERATION | |
| CPU | 32 bit CISC / 96 MHz, from 512 Kbytes + 32 Kbytes |
| SRAM | 96 Kbyte, from (storage) 1 Mbyte |
| MEMORY | |
| SYSTEM FLASH | 512 KB + 32KB |
| STORAGE FLASH | 1 MB |
| RAM | 96 KB |
| POWER | |
| CURRENT CONSUMPTION (DURING CHARGING) | Less than 500 mA |
| BATTERY | Lithium polymer, 600 mAh (typ.) |
| CONTINUOUS USE TIME | 10 hours or more |
| CHARGING METHOD | Electromagnetic induction type non-contact power feed, |
| OPERATING (CHARGING) VOLTAGE RANGE | 4.5 ~ 5.5V |
| PHYSICAL | |
| DIMENSIONS (WXHXD) | 1.42 x 3.27 x 0.85 in (36.0 x 83.0 x 21.6 mm) |
| BODY WEIGHT | 2 oz (60 g) |
