Opticon C-41S

$90.13 (incl. GST)

POSMarket SKU: Z2070

13894: C-41S CCD Scanner, USB (HID) Interface, Black

Opticon C-41S USB CCD Linear Barcode Scanner. Featuring the capability of scanning barcodes from LCD screens and mobile phones...

Product Overview

The Opticon C-41S is a durable handheld CCD barcode scanner that features a simple ergonomic design and enhanced decoding algorithms for ultra-fast barcode scanning at a speed of 300 scans per second. Due to the wide optical window it is easier to scan all 1D barcodes. It’s capable of scanning barcodes from LCD screens and mobile phones. The ergonomic design ensures a perfect balance when the scanner rest comfortably in your hand. The scanner looks good on the counter of any store of service desk, blending in with the design of the environment.

The scanner is available with a USB interface and is easily programmable to suite your application. This scanner is really easy to use; the plug and scan experience make this scanner very suitable for first-time users as well as long time users. The white version is anti-microbial, making it perfect for the healthcare market.

Features
  • Cabled, handheld CCD barcode scanner that's reliable and affordable
  • Enhanced decoding algorithms for ultra-fast (300 scans/second) barcode scanning
  • Single red LED aiming line helps to quickly find the appropriate scanning position
  • Reads 1D barcodes from LCD screens and mobile phones
  • Durable—survives 1.5 meter drop to concrete
  • IP42 rating against dust and moisture
  • Trigger modes: manual and auto trigger
  • Compact size and weight: 55.9 x 33.8 x 154 mm (W x H x D) and 55 grams
  • Communication interface USB
  • Available in black or white (the white version is antimicrobial)
  • Backed by a two year warranty

Product Specifications

Scan EngineCCD linear image sensor 1500 pixels
Light SourceRed LED
Scan PatternSingle Line
Scan Rate300 scans/sec
Motion ToleranceN/A
Image CaptureN/A
Capture AreaN/A
Contrast RatioN/A
ResolutionMin. Resolution at PCS 0.9: 0.076 mm
Depth of fieldAt Code 39,
40 - 90 mm (0.127 / 5 mil)
35 - 120 mm (0.15 mm / 6 mil)
20 - 220 mm (0.25 mm/ 10 mil)
30 - 320 mm (0.5 mm / 20 mil)
45 - 600 mm (1.0 mm / 39 mil)
Tilt Angle+/- 25°
Pitch Angle+/- 50°
Skew Angle+/- 65°
Ambient Light Immunity10,000 Lux Max.
Symbologies supportedBARCODE (1D):
JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS) (exl.stacked), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSM-ISSN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
POSTAL CODE:
Chinese Post, Korean Postal Authority Code
Programming MethodScan codes in Manual
Driver available
Indicators/ControlsLED
Buzzer
Operating ModesTrigger
Communication TypeCable
Communication TechnologyN/A
InterfacesUSB: Ver. 2.0, HID/COM (VCP)
RS232: DB9Pin Female connector with DC Jack for external power supply
Not Multi Interface
Supply VoltageUSB: 4.5V to 5.5
RS232: 5.5-6.5V
Power ConsumptionN/A
Drop SpecificationDesigned to withstand repeated 1.5m drops to concrete
Vibration Test 10-100Hz with 2G for 1 Hour
Environmental SealingIP42
ESD ProtectionN/A
Operating Environment0° ~ 50°C, Relative Humidity 5 - 95% none condensing
Storage Environment-20° ~ 60°C, Relative Humidity 5 - 95% none condensing
EMC/Safety StandardsCE, FCC, VCCI, RoHS, IEC62471, EN 61000, EN55022, EN55024
External Dimensions (WxDxH)Scanner: 55.9 x 154 x 33.8 mm
WeightScanner 55 g
