Newland FR42
POSMarket SKU: Z20456
NLS369-10200: 2D WIRELESS DESKTOP CPU-BASED DECODING 2D IMAGER DIRECT BT CONNECTION INCL BT USB DONGLE USB TYPE-C
Encased in an IP52-sealed, drop-resistant (up to 1.5m) housing with no movable components, the FR42-BT reinforces its durability both internally and externally, making it well-suited for challenging outdoor settings.
Product Overview
The FR42-BT, built into an IP52-sealed and drop resistant (1.5m) housing with no moving parts fortifies itself inside and out, is suitable for the tough outdoor environments.
New Generation Product in Simple Appearance
The first wireless desktop products by Newland whose integrated structure design can be placed on the desktop to scan the code without holding it, and it can also be flexibly grasped on both sides.
No Fear of Power off
The battery can be replaced easily and charged respectively.
Outstanding Performance
The FR42-BT is a barcode scanning powerhouse. The megapixel camera allows users to scan 1D and 2D barcodes, including barcodes displayed in a variety of filmed screens, with impressive speed and ease.
Reliable and Stable Wireless Communication
Adopting Bluetooth 5.0 dongle which is strong anti-interference and stable to transmit the data.
Superior Motion Tolerance
Exceptional motion tolerance (1.8m/s) and large FOV (horizontal 62°, vertical 54°) enhance user experience.
Product Specifications
| Image Sensor | 1080*1280 CMOS |
| Illumination | White LED |
| Symbologies |
2D:
1D:
|
| Resolution | =3mil |
| Typical Depth of Field | EAN-13: 10mm-130mm (13mil) QR Code: 15mm-110mm (15mil) Code 39: 35mm-80mm (5mil) |
| Scan Angle | Pitch: ±60°, Roll: 360°, Skew: ±65° |
| Min. Symbol Contrast | 15% |
| Field of View | Horizontal 62°, Vertical 54° |
| Motion Tolerance | 1.8m/s |
| Physical Dimensions (L×W×H) | 82.0×77.0×146.0mm |
| Weight | 209g |
| Notification | Beep, LED |
| Interfaces | Bluetooth 5.0 BLE and HID, Bluetooth Dongle CDC/KBW/HID-POS |
| Operating Voltage | 5VDC±5% |
| Operating Temperature | -10°C to 55°C (14°F to 131°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | 5%~95% (non-condensing) |
| ESD | ±12 KV (air discharge); ±8 KV (contact discharge) |
| Drop | 1.5m/4.9ft |
| Sealing | IP52 |
| Battery Charge Temperature | 0°C to 45°C (32°F to 113°F) |
| Wireless Radio Technology | Bluetooth 5.0 |
| Communication Distance | Bluetooth 5.0: 50m/164ft (direct line of sight in the open space) |
| Battery | 2000 mAh lithium-ion battery |
| Expected Charge Time | 5 hours |
| Expected Battery Life | 9.5 hours of continuous operation (scan once per 3 seconds) 16 hours of continuous operation (scan once per 10 seconds) |
| Certifications | IEC 62471. RoHS, CE RED (BT only), FCC ID (BT only), IEC 60068-2-31, IEC 60529 |
