KOAMTAC KDC300
POSMarket SKU: Z2100
This product has been discontinued by the manufacturer. Please contact our team on 1300 737 998 for advice on a suitable replacement or we may be able to source refurbished units.
2D Imager Bluetooth Barcode Scanner and Data Collector...
Product Overview
The KDC300 comes complete with an easy-to-replace rechargeable battery that can recharge from any USB port allows more than 10,000,000 barcode scans. With 8MB of on-board memory that stores 409,600 barcodes, memory shortages are no longer a concern. The KDC was the world's first MFi-certified Bluetooth barcode scanner by Apple, and comes with KTSync; software and SDK for Android, Blackberry, iOS (iPad, iPhone, iPod touch), Mac OS X and Windows devices. KTSync; includes a keyboard wedging feature and application generation tool.
Feature
- SR or SF 2D Adaptus 5 Imaging Engine
- Decodes all major 1D, 2D symbologies and OCR-A/B
- Superior scanning performance with the top of the line imager scan engine
- Bluetooth V2.1+EDR, Class 2, HID/SPP/MFi
- Bright 1" OLED display
- Optional full integration with IOS (MFI)
- Rechargeable Li-ion battery with user-accessible compartment for easy replacement
- Large data memory (Basic 160KB, Optional 4MB)
- Powerful Keyboard emulator with keyboard wedging, application generation, DB look up and inventory program.
Product Specifications
| Processor | ARM9 32-bit |
| Development Environment | SDK for PC, Pad and Smartphone application Application generation tool Database lookup feature Inventory management feature |
| Operating Platform | Proprietory |
| Real-Time Clock | Quartz RTC for timestamp |
| Memory | Standard Flash ROM: 160KB Optional 4MB RAM: 64 KB |
| Memory Expansion | N/A |
| Scan Engine | Image Sensor : 752 x 480 CMOS sensor (Adaptus 5.0 Technology) Scan Range: SR: 53~335mm SF: 51~226mm |
| Bar-code Type | Barcode (1D): JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128, Interleaved 2 of 5, Code 3 of 5, MSi, Plessey, Posicode, GS1 DataBar Omni, GS1 DataBar limited, GS1 DataBar expanded, S2of5IA, S2of5ID, TLC39, Telepen, Trioptic Barcode (2D): AztecCode, AztecRunes, CodablockF, Code 16K, Code49, DataMatrix, MaxiCode, MicroPDF, PDF417, QRCode, HanXin Code Postal Codes: AusPost, CanadaPost, ChinaPost, JapanPost, KoreaPost, KixPost, Planet Code, Postnet (US), UKPost OCR Fonts: OCR-A, OCR-B, OCRUSCurrency, OCRMICRE13BB, OCRSEMIFONT |
| Keyboards | 3 keys total, 2 navigation keys, 1 scan key |
| Audio | Buzzer |
| Display | Bright 1" OLED Display |
| Camera | N/A |
| I/O Ports | Build in Ultra Mini USB port |
| Radio Options | Bluetooth V2.1+EDR, Class 2, HID/SPP |
| Battery | Rechargeable battery: Lithium-Ion Polymer 3.7V 650mAh |
| Battery Life | N/A |
| Environmental Sealing | N/A |
| Mechanical Shock | Withstands drops from 1.2 m onto concrete with Rubber case |
| ESD Protection | N/A |
| External Dimensions (WxDxH) | 37 x 83 x 21 mm |
| Weight | 54g with Battery |
| Operating Environment | 0 ~ 45°C RH 5-85% non condensing |
| Storage Environment | -20 ~ 45°C RH 5-85% non condensing |
| Product Compliance | C-Tick, CE, FCC, EMC, TELEC |
