KOAMTAC KDC-350
POSMarket SKU: Z2144
This model is available in 7 different configurations. Select a configuration below or contact our experts on 1300 737 998.
1D and 2D Wireless Barcode Scanner with NFC Reading Capabilities and WiFi, 19-key options...
Product Overview
KDC350 enables diverse mobile Auto-Identification applications for collecting and storing barcode data. A built-in display and keypad eliminate blind erroneous data collection and enable interactive data collection processes. An easy-to-replace rechargeable battery that can recharge from any USB port allows more than 25,000,000 barcode scans. With 4MB of on-board memory that stores over 100,000 product databases, memory shortages are also no longer a problem.
Features
- 1D Laser (Normal & Long Range) and 2D Imager Models
- Decodes all major 1D, 2D symbologies and OCR-A/B depending on Scan engine
- Bluetooth V2.1+EDR, Class 2, HID/SPP/MFi
- Bright 1" OLED display
- Optional full integration with IOS (MFI)
- 48 Channel GPS Receiver (Optional)
- NFC (Optional)
- 19 Key Keypad
- Rechargeable Li-ion battery with user-accessible compartment for easy replacement
- Large data memory (4MB)
- Powerful Keyboard emulator with keyboard wedging, application generation, DB look up and inventory program.
Product Specifications
| Processor | ARM7 32-bit |
| Development Environment | SDK for PC, Pad and Smartphone application Application generation tool Database lookup feature Inventory management feature |
| Operating Platform | Proprietory |
| Real-Time Clock | Quartz RTC for timestamp |
| Sensors | Optional NFC Sensor; MIFARE Ultralight, MIFARE Ultralight C tag |
| Memory | Flash ROM: 256KB Program, 4MB user Data RAM: 64 KB |
| Memory Expansion | N/A |
| Scan Engine | Laser scan Engine, choice of Opticon, Honeywell or Motorola or Honeywell 2D Imager (choice of SR & SF) |
| Bar-code Type | Barcode (1D): JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128, Interleaved 2 of 5, Code 3 of 5 |
| Keyboards | 19 Alphanumeric keys including scan and Scroll buttons |
| Audio | Buzzer |
| Display | Bright 1'' OLED Display |
| Camera | N/A |
| I/O Ports | Build in Ultra Mini USB port |
| Radio Options | Bluetooth V2.1+EDR, Class 2, HID/SPP/MFi Optional GPS; PT9250 48 channel |
| Battery | Rechargeable battery: Lithium-Ion Polymer 3.7V 1200mAh |
| Battery Life | N/A |
| Environmental Sealing | IP65 |
| Mechanical Shock | Withstands drops from 1.5 m onto concrete |
| ESD Protection | N/A |
| External Dimensions (WxDxH) | 43 x 94 x 24 mm |
| Weight | 85g with Battery |
| Operating Environment | -10 ~ 50 C RH 5-90% non condensing |
| Storage Environment | -20 ~ 60 C RH 5-90% non condensing |
| Product Compliance | C-Tick, CE, FCC, MIC, TELEC, Laser Safety: IEC 60825-1 Class 2, FDA CDRH Class II |
