KOAMTAC KDC-250
POSMarket SKU: Z2251
This product has been discontinued by the manufacturer. Please contact our team on 1300 737 998 for advice on a suitable replacement or we may be able to source refurbished units.
The KDC-250 enables diverse mobile Auto-Identification applications for collecting and storing barcode data. Bluetooth communications, Laser Scanner. A built-in display eliminates blind erroneous data collections and enables interactive data collection processes. An easy-to-replace rechargeable battery that can recharge from any USB port. Optional GPS Receiver.
Product Overview
- Laser Scan Engine
- Decodes all major 1D symbologies
- Bluetooth V2.1+EDR, Class 2, HID/SPP/MFi
- Bright 1'' OLED display
- Optional full integration with IOS (MFI)
- Optional 48 Channel GPS Receiver
- Rechargeable Li-ion battery with user-accessible compartment for easy replacement
- Large data memory (Basic 160KB, Optional 4MB)
- Powerful Keyboard emulator with keyboard wedging, application generation, DB look up and inventory program.
Product Specifications
| Processor | ARM7 32-bit |
| Development Environment | SDK for PC, Pad and Smartphone application Application generation tool Database lookup feature Inventory management feature |
| Operating Platform | Proprietory |
| Real-Time Clock | Quartz RTC for timestamp |
| Memory | Standard Flash ROM: 160KB Optional 4MB RAM: 64 KB |
| Memory Expansion | N/A |
| Scan Engine | Laser Scan Engine Scan Rate: 100 Scans/sec |
| Bar-code Type | Barcode (1D): JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128, Interleaved 2 of 5, Code 3 of 5, MSi, Plessey, Posicode, GS1 DataBar Omni, GS1 DataBar limited, GS1 DataBar expanded, S2of5IA, S2of5ID, TLC39, Telepen, Trioptic |
| Keyboards | 3 keys total, 2 navigation keys, 1 scan key |
| Audio | Buzzer |
| Display | Bright 1'' OLED Display |
| Camera | N/A |
| I/O Ports | Build in Ultra Mini USB port |
| Radio Options | Bluetooth V2.1+EDR, Class 2, HID/SPP Optional GPS Receiver: PT9250 48 Channel |
| Battery | Rechargeable battery: Lithium-Ion Polymer 3.7V 650mAh |
| Battery Life | N/A |
| Environmental Sealing | N/A |
| Mechanical Shock | Withstands drops from 1.2 m onto concrete with Rubber case |
| ESD Protection | N/A |
| External Dimensions (WxDxH) | 37 x 83 x 21 mm |
| Weight | 57g with Battery |
| Operating Environment | 0 - 45 degree C RH 5-85% non condensing |
| Storage Environment | -20 - 45 degree C RH 5-85% non condensing |
| Product Compliance | Laser Safety: IEC/CDRH Class II C-Tick, CE, FCC, EMC, TELEC |
