Honeywell Granit 1280i
POSMarket SKU: Z4815
This model is available in 3 different configurations. Select a configuration below or contact our experts on 1300 737 998.
The Granit 1280i industrial-grade laser scanner goes the distance. With the ability to read as close as 8.9cm all the way out to 16.5m away. Designed to read nearly all 1D Linear barcodes across a wide depth of field the 1280i is the perfect choice to increase your workers productivity in harsh industrial environments.
Product Overview
The 1280Ii scanner gives you aggressive laser barcode reading with unrivaled accuracy, along with enhanced scanner feedback to maintain productivity in noisy and poorly lit environments. The result is a confidence-building, can-do workflow tool for your business.
Features
- Full range linear depth of field lets you scan out to 16.5 m on 100 mil retro-reflective labels, or as close as 8.9 cm on 7.5 mil high-density bar codes and everything in between.
- Best-in-class durability with IP65-rated housing maximizes operator productivity in the harshest of environments and lowers overall cost of ownership.
- Built to survive 5,000 tumbles from 1m and 50 drops to concrete from 2m - even at temperatures as low as -30C
- Super bright LEDs, enhanced beeper volume, vibrating tactile response, and selectable "good read" visual indicators counter loud machinery and poor lighting conditions, ensuring rapid feedback and eliminating redundant scanning.
- Optional industrial grade cable that's tested to withstand 300,000 90 degree bends at -30C and continues to communicate when 60 pounds of force is applied.
Product Specifications
| MECHANICAL | |
| Dimensions (LxWxH) | 133 mm x 75 mm x 195 mm |
| Weight | 335 g |
| ELECTRICAL | |
| Input Voltage | 4.0 to 5.5 VDC |
| Operating Power | 1.80 W (360mA @ 5 VDC) |
| Standby Power | 0.75 W (150mA @ 5 VDC) |
| Host System Interfaces | True RS232 |
| ENVIRONMENTAL | |
| Operating Temperature | -30C to 50C |
| Storage Temperature | -40C to 70C |
| Humidity | Up to 95% relative humidity, non-condensing |
| Drop | Designed to withstand 50, 2m (6.5 ft) drops to concrete at across temperature range |
| Tumble | 5,000 1m (40 in) tumbles |
| Environmental Sealing | IP65 |
| Light Levels | 0 to 70,000 lux (6,503 foot-candles) |
| ESD | +/-20Kv air discharge, +/-8kV contact discharge |
| SCAN PERFORMANCE | |
| Scan Pattern | Single Scan Line |
| Scan Angle | 13.5 Degrees Typical |
| Symbol Contrast | 35% gray on white contrast |
| Pitch, Skew, Tilt | +/-65, +/-65, +/-10 Degrees |
| Warranty | 3 year factory warranty |
