Datalogic QM2131
POSMarket SKU: Z2082
This model is available in 2 different configurations. Select a configuration below or contact our experts on 1300 737 998.
Featuring Datalogic's STAR 2.0 Cordless System for narrow band 433 Mhz radio communications, the QM2131 linear imager provides secure radio communications with no risk of interference from Wi-Fi infrastructure and very low sensitivity to obstacles like concrete walls, wood or metal shelves.
Product Overview
The QuickScan QM2131 imagers extra-wide field of view and extra-long scan line makes reading long bar codes in closer distances much easier. The sharp and highly visible scan line makes the scanner more user-friendly to use, while the enhanced depth of field enables bar codes to be read at an intuitive distance. The stylish design is the signature of the QuickScan series, completing a consistent family appearance.
Features- Cordless 1D Linear Imager Scanner
- Extra-wide scan angle and extra-long scan line
- Sharp and highly visible scan line
- Enhanced depth of field for general purpose scanning applications
- Datalogic's STAR2.0 Cordless System with up to 25.0 m / 82.0 ft range
- Secure radio communications, interference-free with low sensitivity to obstacles
- Easy, tool-free, user-replaceable, long-lasting lithium-ion battery
- New battery package allows simultaneous change of charging contacts during battery replacement
- Alternative battery recharging through USB /microUSB cable
- Datalogic's patented 'Green Spot' technology for good-read feedback
- EASEOFCARE Service Plans offer a wide range of service options to protect your investment, ensuring maximum productivity and ROI
Product Specifications
| Scan Engine | Linear Imager |
| Light Source | Red LED 610 - 650 nm |
| Scan Pattern | Single Line |
| Scan Rate | 400 reads/sec |
| Motion Tolerance | N/A |
| Image Capture | N/A |
| Capture Area | N/A |
| Contrast Ratio | Minimum 25% |
| Resolution | 0.102 mm / 4 mils (Linear Barcodes) |
| Depth of field | 4 mils - 3.0 to 11.0 cm 5 mils - 2.0 to 15.0 cm 7.5 mils - 2.0 to 25.0 cm 10 mils - 2.0 to 36.0 cm 13 mils - 1.0 to 45.0 cm 20 mils - 4.0 to 70.0 cm Performance may be impacted by Bar code quality and environmental conditions |
| Tilt Angle | +/- 45 Degrees |
| Pitch Angle | +/- 65 Degrees |
| Skew Angle | +/- 70 Degrees |
| Ambient Light Immunity | 0 to120,000 Lux |
| Symbologies supported | 1D:Auto-discriminates all standard 1D codes including GS1 DataBar linear codes Stacked Codes: EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectiona; UPC A/E Composites |
| Programming Method | Automatic: Software commands through the RS-232 / USB interfaces Datalogic Aladdin: Windows configuration program |
| Driver available | JavaPOS, OPOS Utilities |
| Indicators/Controls | Beeper (Adjustable Tone and Volume) Datalogic's "Green Spot" Good read feedback Good read LED |
| Operating Modes | Trigger, Auto-Trigger |
| Communication Type | Star 2.0 Cordless System |
| Communication Technology | 433 MHz Radio Frequency Point to Point Configuration Open Air Radio Range: 25 m |
| Interfaces | To Base : USB, Keyboard Wedge and RS232 Multi Interface |
| Supply Voltage | 4.75 - 14 VDC Battery: Li-ion 1400mAh, Charge time with external Power supply 4 Hrs at 12V Reads per charge: 30000+ |
| Power Consumption | N/A |
| Drop Specification | Designed to withstand repeated 1.5m drops to concrete |
| Environmental Sealing | IP42 |
| ESD Protection | +/- 16 kV air discharge |
| Operating Environment | 0 Degreees ~ 50 C, Relative Humidity up tp 90% none condensing |
| Storage Environment | -40 Degrees ~ 70 C, Relative Humidity up tp 90% none condensing |
| EMC/Safety Standards | |
| External Dimensions (WxDxH) | Scanner: 41 x 91 x 163 mm |
| Weight | Scanner 190 g Base 215 g |
