Datalogic PowerScan PD9330
POSMarket SKU: Z5077
This product has been discontinued by the manufacturer. Please contact our team on 1300 737 998 for advice on a suitable replacement or we may be able to source refurbished units.
The Datalogic PowerScan PD9330 is a rugged industrial handheld scanner. This reader's mechanics have been developed and tested to withstand extreme environmental conditions, maintaining consistent reading performance without degrading performance or reliability. The PowerScan PD9330's ergonomic enclosure is lightweight and well-balanced to ensure optimal operator comfort during scan-intensive operations. A built-in metal tether hook is included on the PowerScan PD9330 for suspended applications, which ensures workplace productivity.
Product Overview
- Optics available in:
- Standard Range: contact up to 1.6 m / 5.2 ft
- Auto Range: up to 11.5 m / 37.0 ft. on reflective codes
- Datalogic"s 3GL technology and a loud beeper for good-read feedback
- Built-in multiple interfaces (RS-232, Keyboard wedge and USB)
- Operates over a wide range of temperatures
- Water and Particulate Sealing Rating: IP65
- Drop resistance to 2.0 m / 6.5 ft
- Ergonomic shape provides hours of tireless data collection for the user
- EASEOFCARE Service Plans offer a wide range of service options to protect your investment
Product Specifications
| General Information | ||
| Category | Light pen or barcode scanner | |
| Description | Datalogic PowerScan PD9330 Auto Range - Barcode scanner - handheld - 35 scan / sec - decoded - keyboard wedge, RS-232, USB | |
| Manufacturer | Datalogic | |
| UNSPSC | 43211707 | |
| Main Specifications | ||
| Dimensions & Weight / Depth | 11 cm | |
| Dimensions & Weight / Height | 21.2 cm | |
| Dimensions & Weight / Weight | 375 g | |
| Dimensions & Weight / Width | 7.4 cm | |
| Header / Brand | Datalogic | |
| Miscellaneous / Product Color | Black;Yellow; | |
| Packaged Quantity | 1 | |
| Scanner / Type | Barcode scanner | |
| Service & Support / Type | 3-year warranty | |
| Barcode | ||
| Connectivity Technology | Wired | |
| Decode Capability | EAN/JAN, Code 93, Code 39, ISBN, GS1 DataBar, Code 32, Code 39 Full ASCII, Codabar, Code 128, UPC, Interleaved 2 of 5, Standard 2 of 5, EAN-128, MSI | |
| Features | Datalogic Three Green Lights (3GL), Green Spot technology | |
| Interface Type | Keyboard wedge, RS-232, USB | |
| Light Source Wave Length | 630-680 nm | |
| Max Working Distance | 11.5 m | |
| Minimum Bar Width | 7.5 mil | |
| OK Notification | Beeper, LED indicator | |
| Pitch (Degrees) | 60 | |
| Print Contrast Signal (PCS) | 25% | |
| Scan Element Type | Visible laser diode | |
| Scan Mode | Single-pass | |
| Scan Speed | 35 scan / sec | |
| Skew (Degrees) | 65 | |
| TTL Decoding | Decoded | |
| Dimensions & Weight | ||
| Depth | 11 cm | |
| Height | 21.2 cm | |
| Weight | 375 g | |
| Width | 7.4 cm | |
| Environmental Parameters | ||
| Drop Specification | 2 m to concrete | |
| Humidity Range Operating | 0 - 95% (non-condensing) | |
| Max Operating Temperature | 50 °C | |
| Min Operating Temperature | -20 °C | |
| Expansion / Connectivity | ||
| Interfaces | 1 x keyboard wedge ¦ 1 x RS-232 ¦ 1 x USB | |
| General | ||
| Color | Black/yellow | |
| Type | Barcode scanner - handheld | |
| Manufacturer Warranty | ||
| Service & Support | Limited warranty - 3 years | |
| Miscellaneous | ||
| Cables Included | 1 x serial cable - external - 2.44 m | |
| Compliant Standards | RoHS, IP65, EN 60825-1 Class 2, CDRH Class II, China RoHS | |
| Power | ||
| Voltage | DC 4.5 - 30 V | |
| Software | ||
| Software Included | Datalogic Aladdin, OPOS/JavaPOS Drivers | |
